Features

  • Smoothly vibrating.. long service life.
  • Few wear parts, low power consumption and notable energy conservation.
  • Simple structure, convenient installation and operation.

Technical Parameters

Model Hopper Size
(mm * mm)		 Max. feed size
(mm)		 Capacity
(t/h)		 Electric motor
Power (kw)		 Dimensions
(mm)
GZD/ZSW:FTFD250*75 2500*750 300 50-80 1.5*2 2580*1 430*600
GZD/ZSW:FTFD300*90 3000*900 500 80-150 3.0*2 3050*1 430*1550
GZD/ZSW:FTFD370*100 3700*1050 700 100-200 3.7*2 3980*1878*866
GZD/ZSW:FTFD490*110 4900*1100 900 120-300 5.5*2 5200*1900*950
GZD/ZSW:FTFD500*120 5000*1200 1000 200-400 5.5*2 5450*2000*900
GZD/ZSW :FTG380*96 3800*960 700 100-250 11 3882*168 4*1340
GZD/ZSW :FTG490*110 4900*1100 800 120-300 15 4957*18 41*1365
GZD/ZSW :FTG590*110 5900*1100 900 200-350 22 6000*18 41*1365
GZD/ZSW :FTG600*130 6000*1300 1000 400-600 22-30 6028*2580*2083
GZD/ZSW :FTG600*150 6000*1500 1000 450-650 30-37 6271*2369*2668
GZD/ZSW :FTG600*180 6000*1800 1000 600-1000 37-45 6375*2653*2913
